DrayTek Vigor2136ax

*****

SKU: 4710484747686

Pieces

- +

€ 186,00

Temporarily out of stock

Notify me when it becomes available again

CONTACT US FOR PROJECT PRICES

+30 210 6777007 info@draytek.gr

Compare

Description
Specifications
Downloads

DrayTek Vigor2136ax wireless broadband router features a 2.5G WAN port and is designed for businesses and demanding users seeking advanced connectivity, security, and management features.

Its hardware interface includes two 2.5G ports, one for WAN and one for LAN, which can be configured as a second WAN. Additionally, it has three LAN ports, two USB ports, and buttons for factory reset and WLAN/WPS.

Vigor2136ax supports Wi-Fi 6 with up to 16 SSIDs (8 per band), excellent roaming, band steering, advanced wireless security, and wireless user access management.

Vigor2136ax runs DrayTek’s new DrayOS 5 operating system, supporting IAM (Identity and Access Management), allowing the application of policies for managing and controlling user access to business resources. It also supports up to sixteen VPN tunnels, enabling Site-to-Site VPN and Teleworker VPN creation via IPsec, IKEv1/IKEv2, IKEv2-EAP, IPsec-XAuth, OpenVPN, and WireGuard protocols.

Advanced features of the Vigor2136ax include bandwidth management policies (QoS, VoIP prioritization, IP-based bandwidth limits, etc.), failover capability, WAN data budgeting, support for up to 8 VLANs (802.1q Tag-based, Port-based), a built-in DHCP server, and a Hotspot Web Portal with "click through" authentication and external portal server support. It also provides advanced security features, traffic monitoring, and can function as a virtual controller for free management of up to 20 access points (up to 7 in mesh mode) and 5 DrayTek switches. It is also manageable through DrayTek’s VigorACS platform.

Fixed WAN ports:	1 x 2.5GbE RJ-45
WAN/LAN Switchable Ports:	1 x 2.5GbE RJ-45
Managed by VigorACS:	YES
Hotspot Web Portal:	YES
USB ports:	2 x USB 2.0 for User Management, File Explorer, Device Status, Printer Server, Temperature, Sensor, USB WAN
WLAN - 2.4GHz Standard(6):	-
WLAN - 5GHz Standard(6):	-
Antenna:	2 x External Detachable + 1 x 5GHz Internal PIFA (Gain: 2.7 dBi @ 5GHz, 2.6 dBi @ 2.4GHz)
Fixed LAN ports:	3 x GbE, RJ-45
SIM slots:	-
LTE ANTENNA:	-
FXS RJ-11 ports:	-
Console Port:	-
Max. Concurrent VPN Tunnels:	16
Max. Concurrent OpenVPN + SSL VPN:	-
WiFi 6:	YES
High Availability:	-
Mesh Network:	7 x VigorAP
Central management:	20 x VigorAP, 5 x VigorSwitch
Max.Number of VLAN:	8
19'' Rack Mountable:	-
